Description
They are recommended for pumping clean water without abrasive particles and liquids that are chemically non-aggressive to the materials from which the pump is made. Thanks to their reliability and ease of use, they are widely used in the domestic and civil sectors, in particular for the distribution of water in conjunction with small and medium-sized autocalve tanks, for decanting and for irrigation of vegetable gardens and gardens. The installation must be carried out in closed places or in any case protected from bad weather.
Features
Liquid type: clean water
Uses: domestic, civil
Uses: water supply, air conditioning systems, pressurization systems, cooling systems, irrigation, tank transfer
Typology: surface
Family: centrifuges
Scope of services:
Flow rate at 10 l / min, the head is 22 meters.
Flow rate at 80 l / min, the head is 14 meters.
Application limits:
Liquid temperature from -10 C up to +90 C
Ambient temperature up to +40 C
Power:
0.37kW - 0.5Hp
Manometric suction height up to 6 m
Max pressure in the pump body: 6 bar
Continuous duty S1
1 "suction and delivery ports
